WhisperCeiling® DC Fan|Light 110-130-150 CFM

Model:

  • FV-1115VQL1
Featured Specs
WhisperCeiling® DC™ fan/LED light with built-in Pick-A-Flow® speed selector switch allows you to select your required airflow (110-130-150 CFM). Features an ECM motor with SmartFlow® technology and a Flex-Z Fast installation bracket. Can be used to comply with the latest codes and standards.
Contact Sales Find A Dealer

  • Revolutionary ECM motor with SmartFlow™ technology for optimum CFM output
  • Pick-A-Flow® Speed Selector – one fan, you choose the CFM (110, 130, 150 CFM models)
  • Flex-Z Fast bracket provides flexible, fast & trouble-free installation, even from below the ceiling
  • Lighted models incorporate one long-life, 10W dimmable LED chip panel with <1W LED night light for warm, energy efficient illumination
  • Elegant grille design compliments the aesthetics of any bathroom

Featured Specs

Model FV-1115VQL1
Advanced Features Single Speed
Air Volume (CFM) 150, 144, 130, 131, 110, 110
Blower Wheel Type Sirocco
California Title 24 Compliant Yes
Color Rendering Index 90
Color Temperature (Kelvin) 3,000
Current (Amps) 0.21, 0.30, 0.17, 0.27, 0.13, 0.22
Duct Diameter 6"
Energy Efficiency (CFM/Watt) 11.7, 7.5, 12.8, 7.8, 14.5, 8.7
Grille Size (in sq.) 13"
Gross Weight (lbs) 11.9
Lamp Watts 10.0
Lumens (lm) 700
Lumens Per Watt (LPW) 70
MAX. Current (Amps) 0.30
Mfg in ISO 9001 Certified Facility Yes
Motor Type (AC/DC) DC
Mounting Opening (in sq.) 10-1/2"
Night Light 0.2
Noise (Sones) 0.5, 0.8, <0.3, 0.7, <0.3, 0.5
Power Consumption (Watts) 13.0, 19.3, 10.3, 17.0, 7.7, 12.8
Power Rating (V/Hz) 120/60
Product Family Name WhisperCeiling DC
Rated Life (hours) 50,000
Speed (RPM) 1342 1480 1016, 1268, 867, 1185, 768, 1097
Static Pressure in inches w.g. 0.1, 0.25, 0.1, 0.25, 0.1, 0.25
Thermal Fuse Protection Yes
Type of Lamp Socket LED Chip
Type of Motor Bearing Ball
UL Listed for Tub/Shower Enclosure when GFCI Protected Yes
UL tub/Shower Enclosure Yes
Washington VIAQ Code Yes

Performance and efficiency perfected with precision spot ventilation fan/LED combo

WhisperCeiling DC comes from a line of time-tested and customer approved quiet, yet powerful and energy efficient ventilation fans. This precision spot ventilation solution improves IAQ by effectively removing moist, polluted air from your bathroom, laundry room, sun room, basement or garage.

ECM motor with SmartFlow™ technology

WhisperCeiling® DC™ is designed to perform as rated. When the fan senses static pressure, its speed is automatically increased to ensure optimal CFM output. This feature provides peace of mind, as the installer doesn’t have to worry about compromising the fan’s performance, even with a complicated duct run

Pick-A-Flow® Speed Technology

Built-in Pick-A-Flow® speed selector provides the unique ability to select your required airflow (110-130-150 CFM) with the flip of a switch.

LED Lighting

Fan/light models feature a contemporary flush mount grille that incorporates a long-life 10W dimmable LED chip panel with <1W LED night light for warm, lasting  energy efficient illumination. Panel specifications include: 3000 Kelvin Warm White/90CRI/700 lumens/70 LPW/ENERGY STAR 2.0 certified/JA-8 compliant for CA Title 24/ 50,000 hours rated average

Long life and lower operating costs

Whether you're running a household or a business, you shouldn't have to replace little things like a vent fan. Panasonic fans use less energy, move larger volumes of air and run cooler, which means they last longer. Our motors are equipped with a thermal-cutoff fuse, greatly reducing the likelihood of overheating and motor failure.

Installation flexibility

The Flex-Z Fast™ installation bracket with articulating joints is ideal for positioning the fan exactly where you want it, in old or new construction.

ENERGY STAR® certified for energy savings

ENERGY STAR® certified vent fans meet strict parameters set by the US Environmental Protection Agency. Panasonic ventilation fans are ENERGY STAR® certified where guidelines exist, and provide greater efficiency and comfort with less noise. High performing motors and improved blade design deliver superior performance and long life you expect from a premium Panasonic ventilation fan. WhisperCeiling® DC™ was awarded 2018 Most Efficient. This mark recognizes WhisperCeiling® DC™ as delivering cutting edge energy efficiency along with the latest in technological innovation. It is an award that represents the best of those products that qualify for ENERGY STAR®.
