Atmosphere Vortex® S-1000 Mixed Flow Fan

Model:

  • S-1000
Vortex® S-line Mixed Flow Fans are designed for residential and light commercial ventilation applications. These compact, powerful, and quiet fans are available in 10” duct diameter and are ideally suited for either supply or exhaust ventilation systems.
Contact Sales

  • Powerful, compact and quiet mixed flow impeller
  • Easy to install - mounting brackets included
  • 10" duct diameter
  • 1082 CFM
  • 100% speed controllable
  • Pre-wired with 120V power cord
  • ETL & AMCA air listed
  • 10-year warranty

The Vortex S-Line motor is 100% speed controllable, highly efficient with low power consumption, built with permanently lubricated ball bearings and provides thermal overload protection with automatic reset.

  • Simple clipping system allows quick removal of the fan for maintenance.
  • Mixed flow impeller design provides quiet operation and high air flow.
  • Internal impeller results in cooler motor operation.
  • Mounting bracket is designed for quick and easy installation.
